1/4" SONY Super HAD DSP CCD color

Picture Elements: NTSC 811H x 508V   PAL 795H x 596V

Horizontal Frequency :NTSC 15.734kHz  PAL 15.625Khz

Vertical Frequency :EIA 60Hz  CCIR 50Hz

Clock Frequency :NTSC 28.636Mhz  PAL 28.375 Mhz

Scanning System - 2:1 Interlace

Horizontal resolution - 450 Lines

Power Supply - 10% 8W(Max) @ 200ma / 670ma(IR on)

Illumination - 0.5 Lux

Signal to Noise ration - 52dB

Electronic Shutter Speed - EIA1/60~1/100,000 sec; CCIR1/50~100,000sec

Lens - Manual zoom lens 3.5mm-8mm

Video Output - 1V pp 75 Ohms

Audio Output - N/A

Day/Night - changes into the monochrome view under 1 Lux (optional upgrade)

Gamma - 0.45

White Balance - Auto

Backlight Compensation - Gain Control - Auto Iris - Internal

Max. pan angle - 360°

Min. pan angle - 22.5° (pan angle programmable by dip switch)

Tile angle - 0-90°

Pan/Tile Speed - Pan 9°/S; Tilt 20°/S

Weight - 640g

Dimensioni - ø75 x 70 mm

Storage Temperature - -30C to +60C

Operating Voltage - 12V DC, 300mA

Operating Temperatures: -10°C to +45°C
